Mission Specialist Ally ROV
The Mission Specialist Ally ROV is engineered to provide optimal power and lift within a compact, maneuverable frame. Equipped with two horizontal and two vertical thrusters, this ROV delivers lateral thrust of 6.1 kg (13.5 lbs) at 1 knot. It is available with two float options: a rounded float ideal for maneuverability in tight spaces and a squared float that offers enhanced payload capacity and subsea battery use.
The vehicle features a spring-loaded vertical manipulator and the Ultra 4K Smart Camera, which includes onboard image processing and neural network capabilities. The modular design supports an upgrade path to the Mission Specialist Defender and other future configurations.
Specifications:
| Dimensions: |
64.1 x 30.5 cm (25.25 x 12") with rounded float 64.1 x 38.1 x 30.5 cm (25.25 x 15 x 12") with squared float & batteries |
| Weight in Air: |
13.6 kg (30 lb) - No Payloads 15.8 kg (34.8 lb) - With Oculus 750 Sonar, A50 DVL, Reach Alpha Manipulator |
| Depth Rating: | 300 m (984 ft) |
| Thrusters: |
2 Horizontal Thrusters: 16.8 kg (37 lbs), 4 Knots 2 Vertical Thrusters: 9.5 kg (21 lbs), 1.5 Knots |
| Lateral Thrust: | 6.1 kg (13.5 lbs), 1 Knot |
